20" Wide All-Freezer, ADA Compliant
(83cm H x 49cm W x 54cm D)
SPECIFICATIONS
Overview
|
|
---|---|
Height of Cabinet | 32.0" (81 cm) |
Height to Hinge Cap | 32.5" (83 cm) |
Width | 19.25" (49 cm) |
Depth | 21.38" (54 cm) |
Depth with door at 90° | 39.5" (100 cm) |
Capacity | 2.8 cu.ft. (79 L) |
Defrost Type | Manual |
Door | Stainless Steel |
Cabinet | White |
US Electrical Safety | ETL |
Canadian Electrical Safety | ETL-C |
Amps | 1.6 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 64.0 lbs. (29 kg) |
Shipping Weight | 67.0 lbs. (30 kg) |
Parts & Labor Warranty | 1 Year |
Compressor Warranty | 5 Years |
UPC | 761101041575 |
Freezer
|
|
Door Swing | RHD |
Reversible | Factory Reversible |
Interior Height | 26.38" (67 cm) |
Interior Width | 14.0" (36 cm) |
Interior Depth | 16.75" (43 cm) |
Thermostat Type | Dial |
Refrigerant Type | R134a |
Refrigerant Amount | 3.0 oz. |
High Side PSI | 210.0 |
Low Side PSI | 105.0 |
Level Legs | 2 |
Interior Drawers | Yes |
Drawers Qty | 4 |
AVAILABLE UPGRADES
Exterior | |||||||
---|---|---|---|---|---|---|---|
|
|||||||
Lock | |||||||
|
FEATURES
32" high meets ADA guidelines
2.8 cu.ft. capacity inside a slim footprint
Top-mounted for convenient security
Allows the unit to be used freestanding
304 grade stainless steel on the cabinet and door
Thin 14mm diameter on vertical stainless steel handle
Efficient performance with reliable temperature stability
Low temperature capability ideal for certain sensitive items
Four clear baskets for convenient and separated storage
Rear mounted to prevent accidental adjustments
Easy to clean, with more depth for storage
Environmentally friendly design with no ozone-damaging chemicals
Pair with FF511LSSHVADA for a complete ADA compliant set
DESCRIPTION
SUMMIT offers a quality selection of ADA compliant 20" wide low temperature all-freezers with the 32" high FS407LADA series. The FS407LSSHVADA is an all-freezer, with manual defrost operation and 2.8 cu.ft. capacity. Designed to operate colder than normal household freezers (-20ºC), the FS407LSSHVADA is ideal for storing select pharmaceuticals, physical therapy samples, frozen food, and other temperature sensitive materials. Four pull-out drawers with clear fronts offer convenient storage solutions. The adjustable thermostat is located in the rear of the model. Designed for freestanding use, the FS407LSSHVADA has a white cabinet with a professional style stainless steel wrapped door and sleek handle. A top-mounted lock adds convenient security. Sized just under 20" wide, the freestanding FS407LSSHVADA has a 32" height to meet ADA guidelines for lower counters. This model can be paired with the FF511LSSHVADA auto defrost all-refrigerator to create a matching set. For a built-in version of this model, see the FS407LBISSHVADA.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
