18" 8 lb. Drain-Free Icemaker

SKU: BIM18SS

No drain required for more flexibility in placing the icemaker

Estimated Time to Ship:

5 to 7 days

Find a dealer

Height:
Standard ADA

Color: Stainless Steel/Black

*Additional features may vary

34.25" H x 17.75" W x 24.0" D
(87cm H x 45cm W x 61cm D)

Overview
Nominal Height	35.0" (89 cm)
Height of Cabinet	34.25" (87 cm)
Nominal Width	18.0" (46 cm)
Width	17.75" (45 cm)
Nominal Depth	24.0" (61 cm)
Depth	24.0" (61 cm)
Depth with Handle	25.75" (65 cm)
Depth with door at 90°	40.0" (102 cm)
Capacity	2.7 cu.ft. (76 L)
Defrost Type	Frost-Free
Door	Stainless Steel
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Amps	1.1
Voltage/Frequency	115 V AC/60 Hz
Weight	82.0 lbs. (37 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101063706
Icemaker
Door Swing	RHD
Reversible	Yes
Daily Ice Production	8.0 lbs. (4 kg)
Ice Storage Capacity	8.0 lbs. (4 kg)
Ice Shape	Crescent
Number of Ice Cube Sizes	1
Interior Light	Yes
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	1.06 oz.
High Side PSI	270.0
Low Side PSI	103.0
Interior Height	23.5" (60 cm)
Interior Width	12.75" (32 cm)
Interior Depth	16.75" (43 cm)
Compressor Step Height	4.5" (11 cm)
Compressor Step Width	12.75" (32 cm)
Compressor Step Depth	4.5" (11 cm)
Level Legs	4
Temperature Range	-22 to 14ºF

Exterior

SSK - Stainless steel kickplate Stainless steel kickplate factory installed	LHD - Left hand door swing Door reversal to left hand swing
Latch - Factory-installed door latch requires manual release to open unit Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.

Built-in capable

Make the best use of space by installing your appliance under the counter

No pump or drain required

Convenient design allows more flexibility in positioning the unit

Ice production

Makes and stores up to 8 lbs. of crescent cubes

Stainless steel door

Fully wrapped in stainless steel for a professional look

Factory installed lock

Keyed lock for a secure interior (2 keys included)

Removable bin

Bucket can be removed for fast and easy cleaning

Digital thermostat

Electronic controls for precise temperature management.

Digital display

Temperature readout can be shown in Celsius or Fahrenheit

Frost-free operation

Eliminates the need to manually defrost the interior

Extra shelves

Adjustable chrome shelves included to accommodate additional items

Reversible door

User-reversible door swing for added flexibility

Professional handle

Stainless steel handle completes the professional look

Flush back

Space saving design with easier cleanability

Fully finished black cabinet

Allows the unit to be used freestanding

CARB Compliant

Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

100% CFC Free

Environmentally friendly design with no ozone-damaging chemicals

Lead-free certified

Complies with California Health and Safety Code 116876 lead leaching requirements per NSF NSF/ANSI/CAN 61-2022 standard, as well as with lead content requirements for ‘lead free’ plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act Section 1417(d) per NSF/ANSI/CAN 372-2022 standard

Summit brings convenient luxury under the counter with built-in icemakers uniquely sized for smaller kitchens.

Sized just under 18 inches wide, the BIM18SS features a front-breathing design for built-in installation, with a fully finished cabinet to also allow freestanding use. The 304 grade stainless steel wrapped door is user-reversible to best fit your setting. We include a pro style handle and front-mounted keyed lock for optional security. No drain or pump is required for use, offering more flexibility in where you place the unit.

Inside, the BIM18SS can produce and hold 8 lbs. of crescent-shaped ice cubes in the removable bucket. Additional chrome shelves allow you to store other frozen items as needed. This unit utilizes frost-free operation to help reduce user maintenance.

With its ideal size and user-friendly design, the BIM18SS is a great solution to keeping a steady supply of ice on hand in smaller kitchen spaces. For this unit sized for ADA compliant counters, see the BIM18SSADA. Matching 18 inch wide refrigerators, beverage centers, and wine cellars are also available. Browse our website to explore our complete selection.

BROCHURE w/ DRAWINGS
BIM18SS.pdf

TECHNICAL DRAWING (.dwg)
SCFF1842_FREEZERA-C2000.dwg

USE & CARE
BIM18SS_IF_ADA_User_Manual_02.2022.pdf

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
