18" Wide Built-In Wine Cellar (Panel Not Included)
1 to 2 days
All tints reject up to 99% of UV rays. Click here to view these options and learn more about their efficiency.
(86cm H x 44cm W x 60cm D)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 34.0" (86 cm) |
| Width | 17.5" (44 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 25.38" (64 cm) |
| Depth with door at 90° | 39.63" (101 cm) |
| Capacity | 2.9 cu.ft. (82 L) |
| Bottles | 29 bottles |
| Defrost Type | Automatic |
| Door | Glass/Panel-Ready Frame |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.0 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 88.0 lbs. (40 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101145631 |
|
Wine Cellar
|
|
| Number of Zones | 1 |
| Door Swing | LHD |
| Reversible | No |
| Adjustable Shelves | Yes |
| Shelf Type | Wood |
| Shelf Qty | 5 |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.64 oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Interior Height 1 | 23.0" (58 cm) |
| Interior Width 1 | 12.25" (31 cm) |
| Interior Depth 1 | 17.5" (44 cm) |
| Compressor Step Height | 4.5" (11 cm) |
| Compressor Step Width | 12.0" (30 cm) |
| Compressor Step Depth | 5.75" (15 cm) |
| Level Legs | 2 |
| Temperature Range | 41 to 72ºF |
| Interior Height 2 | 3.25" (8 cm) |
| Interior Width 2 | 12.25" (31 cm) |
| Interior Depth 2 | 5.25" (13 cm) |
| Sabbath Mode | Yes |
AVAILABLE UPGRADES
| Exterior | |||||
|---|---|---|---|---|---|
|
|||||
| Door | |||||
|
FEATURES
Undercounter single zone wine cellar for built-in or freestanding use
Make the best use of space by installing your appliance under the counter
Meets UL-471 commercial standards
European style articulating door hinge and bracket kit allow easy installation of custom door trim panels to match adjacent cabinetry
Heat-safe glass ensures your collection is protected
Electronic controls for precise temperature management
Temperature readout can be shown in Celsius or Fahrenheit
Black wooden shelves feature stainless steel trim for an added touch of elegance
Unique white lighting located inside the walls offers elegant illumination for the jet black interior
Vertically mounted handle in brushed stainless steel
For this unit with the door opening from the other side, see model CL18WCPNR
Floor is specially slotted to store wine bottles safely in place
Keyed lock located in the kickplate for optional security
Audibly alerts if the interior temperature is too warm
Audible alarm will sound if the door is left ajar for over 60 seconds
Internal fan ensures the interior is evenly cooled from top to bottom
Reduced maintenance and steady temperature performance
Space saving design with easier cleanability
Unit will retain its last settings when power is restored in the event of power loss
Allows the unit to be used freestanding
Smoother opening and a better fit with an integrated European hinge
Holds up to 29 Bordeaux or Burgundy style bottles
Environmentally friendly design with no ozone-damaging chemicals
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
DESCRIPTION
Summit manufactures deluxe undercounter appliances designed to bring modern luxury into the home. The CL18WCPNRLHD is an 18" wide single zone wine cellar. The front breathing design allows built-in installation under counters, while the fully finished cabinet in a jet black finish also enables freestanding use. This unit includes a fully articulating European-style hinge and 2-piece bracket kit that lets you easily install overlay panels over the door trim to create a custom look. Inside, white LED lighting located on the side walls complements the black interior to provide an attractive presentation of your stored collection. A lock is located in the kickplate for convenient security. The CL18WCPNRLHD can store up to 29 Bordeaux or Burgundy style bottles. The black wooden shelves feature stainless steel trim. The interior control panel includes a digital thermostat for easy and intuitive operation, with a readout viewable in Celsius or Fahrenheit. Additional features include a right angle plug for added space savings, sealed back design for easier cleanup, and a Sabbath mode setting. A built-in alarm audibly warns if the door is left ajar or if the unit exceeds recommended temperature, offering added protection for your wine storage. Uniquely styled and fully featured, the CL18WCPNRLHD brings true luxury to small kitchen and wet bar spaces. For a matching beverage center, see model CL181WBVPNR.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
