24" Wide Built-In Beverage Center

SKU: SCR610BLPNR

Stainless steel interior for better sanitation in commercial settings

Estimated Time to Ship:

3 to 5 days

Find a dealer

Color: Panel-Ready

*Additional features may vary

Available with an energy saving door tint to protect the interior from natural and artificial light. Choose from four tint finishes with varying levels of visibility.

All tints reject up to 99% of UV rays. Click here to view these options and learn more about their efficiency.

This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

34.0" H x 23.63" W x 23.5" D
(86cm H x 60cm W x 60cm D)

Overview
Nominal Height	34.0" (86 cm)
Height of Cabinet	34.0" (86 cm)
Nominal Width	24.0" (61 cm)
Width	23.63" (60 cm)
Nominal Depth	24.0" (61 cm)
Depth	23.5" (60 cm)
Depth with door at 90°	45.5" (116 cm)
Capacity	5.0 cu.ft. (142 L)
Defrost Type	Automatic
Door	Glass/Panel-Ready Frame
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	0.8
Voltage/Frequency	115 V AC/60 Hz
Weight	100.0 lbs. (45 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101065526
Refrigerator Features
Sabbath Mode	Yes
Door Swing	RHD
Reversible	Factory Reversible
Shelf Type	Chrome
Shelf Qty	3
Adjustable Shelves	Yes
Thermostat Type	Digital
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.99oz.
High Side PSI	270.0
Low Side PSI	105.0
Level Legs Qty	2
Interior Light	Yes
Temperature Range	36°F to 43°F
Sound Level	37.4 dB
Dimensions
Interior Height	25.0" (64 cm)
Interior Width	19.38" (49 cm)
Interior Depth	17.38" (44 cm)
Compressor Step Height	3.75" (10 cm)
Compressor Step Width	19.38" (49 cm)
Compressor Step Depth	4.63" (12 cm)

Exterior

DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout	PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices
Alarm/Thermometer - Factory-installed alarm with external temperature readout Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations	LHD - Left hand door swing Door reversal to left hand swing
Latch - Factory-installed door latch requires manual release to open unit Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles (NOTE: latch adds 1 1/2" of width to unit)	HG - Hospital grade cord Add a hospital grade cord equipped with green dot plug with the HG suffix
SSK - Stainless steel kickplate Stainless steel kickplate factory installed

Door

T4 Door Tint Neutral door tint in light smoke finish for moderate energy savings	T3 Door Tint Reflective door tint in light blue finish for medium energy savings
T2 Door Tint Tinted door in reflective deep blue finish with high energy savings	T1S Door Tint Reflective door tint in dark smoke finish for maximum energy savings
T1 Door Tint Tinted door in low-E mirror finish for maximum energy savings

Interior

LockBoxSS - Interior locking compartment Interior drop-down compartment with combination lock for use in SCR610BL, SCR1156, FFAR12W, or FFAR121SS units

Commercially approved

ETL-S listed to NSF-7 Standards for use in commercial establishments

Built-in capable

Make the best use of space by installing this unit under the counter and flush with other cabinetry

ENERGY STAR certified commercial performance

Meets ENERGY STAR standards as a commercial refrigerator

Panel-ready door trim

Door frame can be customized with a custom overlay panel (panel frame dimensions: 29 7/8" H x 23 1/8" W at 3/4" minimum thickness)

Double pane tempered glass door

Stainless steel trimmed glass door offers a full display of stored items

Stainless steel interior

Walls are constructed from stainless steel for added strength and easy cleanup

Factory installed lock

Keyed lock for a secure interior

Digital thermostat

Intuitive digital controls ensure easy temperature management

Cantilevered chrome shelves

Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup

Recessed LED lighting

Efficient and attractive lighting illuminates stored products

Open door alarm

Audible alarm will sound if the door is left ajar for over a minute

High temperature alarm

Alarm sounds if the interior temperature rises out of suggested range

Automatic defrost

Reduced user maintenance with automatic defrost

Sabbath mode setting

Optional setting lets you disable the lighting and alarm for up to 48 hours

Temperature Memory Function

Unit will retain its last settings when power is restored in the event of power loss

Fan-forced cooling

Internal fan ensures the interior is evenly cooled from top to bottom

Sealed back

Space saving design with easier cleanability

Fully finished black cabinet

Allows the unit to be used freestanding

Factory-reversible door swing

Door ships with a right hand door swing. For a left hand version, add option "LHD"

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

SUMMIT's commercial beverage centers offer an attractive display for products under reliable cold storage conditions.

The SCR610BLPNR comes in an easy-fitting 24" footprint, with a front-breathing design that can be built-in under counters or used freestanding. The double tempered glass door door features a panel-ready door trim that lets you customize the look to best match adjacent cabinetry (panel dimensions: 29 7/8" H x 23 1/8" W at 3/4" minimum thickness). A factory-installed lock offers additional security. This unit ships with a right hand door swing, but can be ordered to open from the other side by adding option LHD. Users provide their own handle. A digital thermostat is located in the kickplate for easy temperature management.

Inside, the SCR610BLPNR utilizes low maintenance automatic defrost operation with an internal fan to ensure even temperature distribution. Recessed LED lighting offers the perfect display conditions inside the durable and easy-to-clean stainless steel interior. This unit includes three cantilevered chrome shelves to ensure flexible storage that accommodates any item size. High temperature and open door alarms offer added protection.

The SCR610BLPNR is ETL-S listed to NSF-7 for use in commercial settings and is ENERGY STAR certified as a commercial refrigerator.

BROCHURE w/ DRAWINGS
SCR610BLPNR.pdf

TECHNICAL DRAWING (.dwg)
SCR610BL_BEVERAGE_CEN._A-C_2000_.dwg

MSDS INFORMATION
R600a_K.pdf

USE & CARE
ASDG_ASDW_SDHG_SDHW_CL18_ALBV_AL57GPNR_Use_and_Care_Guide_4-29-24.pdf

SUPPORT
PNR_Instructions_-_AL57G_SCR610BL_5-2022.pdf

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
