30" Wide Wall-Mounted Range Hood

SKU: SEH3630

Designed and built in Europe for Summit

DISCONTINUED- REPLACED BY SEH3630SS

36.0" H x 29.63" W x 19.69" D
(91cm H x 75cm W x 50cm D)

Overview
Height of Cabinet	36.0" (91 cm)
Width	29.63" (75 cm)
Depth	19.69" (50 cm)
Cabinet	Stainless Steel
US Electrical Safety	UL
Canadian Electrical Safety	ULC
Amps	4.0
Voltage/Frequency	115 V AC/60 Hz
Weight	40.0 lbs. (18 kg)
UPC	761101022994
Range Hood
Installation	Wall-Mounted
Venting	Convertible w/ Filter Set
Controls	Push Button
Light	Yes
Number of Lights	2
Light Type	Halogen
Number of Fan Speeds	3
Maximum Air Movement	650.0 CFM
Minimum Height	29.38" (75 cm)
Maximum Height	44.31" (113 cm)
Duct Shape	6" Round

Stainless steel construction

Quality material with an elegant look in brushed stainless steel

650 CFM blower

Professional European motor is preinstalled for easy use

Convertible with filter

Designed for ducted use, this range hood can be used in recirculating (ductless) mode when you order SEHCF charcoal filter set

Two aluminum cassette filters

Dishwasher safe filters offer wide filtration area for better ventilation

Adjustable chimney height

Chimney can extend from 29 3/8" to 44 5/16" for the perfect fit over your range

Timer function

Set the unit to ventilate for a 15 minute interval that automatically turns off when complete

Two 50W lights

Includes two preinstalled bulbs

Three-speed fan

Offers more options for ventilation

European made

Designed and manufactured in Europe with all UL-Listed components

6" round ducting

Ideal for most kitchen settings

Installation template included

Scaled template included for guided installation

Noise level information

Speed 1: 51 dB; Speed 2: 54.2 dB; Speed 3: 62.2 dB

SUMMIT PROFESSIONAL introduces a new line of European wall-mounted range hoods designed for outstanding performance and elegant style.

SUMMIT SEH3630 is a 30" wide range hood with a 650 CFM blower. Constructed entirely from stainless steel, it features an adjustable chimney and two aluminum cassette filters with a wide filtration area. The 3-speed fan and 15 minute timer are operated with an intuitive touch controls. Two halogen light bulbs are pre-installed, offering an elegant illumination of your range.

The SEH3630 is designed for ducted use, but may be converted to a ductless (recirculating) range hood when you order an optional charcoal filter set (SEHCF). This model is manufactured in Europe and ships in one box.

BROCHURE
SEH3630.pdf

USE & CARE
SEH3630_SEH3636manual2190.pdf

OTHER
SEH3630_SEH3636_technical_drawing.pdf

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
