30" Wide Electric Coil Range
Next day shipping; multi-piece orders may extend lead time. Call 718-893-3900 ext. 507 to discuss
*Additional features may vary
(112cm H x 76cm W x 61cm D)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Nominal Height | 44.0" (112 cm) |
| Height of Cabinet | 44.0" (112 cm) |
| Nominal Width | 30.0" (76 cm) |
| Width | 30.0" (76 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 24.0" (61 cm) |
| Door | Stainless Steel |
| Cabinet | Black |
| Voltage/Frequency | 220 V AC/60 Hz |
| Weight | 160.0 lbs. (73 kg) |
| Parts & Labor Warranty | 1 Year |
| UPC | 761101012902 |
|
Electric Range
|
|
| Oven Capacity | 3.7 cu.ft. (105 L) |
| Cooktop Surface | Porcelain |
| Element Type | Coils |
| Number of Elements | 4 |
| Element #1 Size | 6.0" (15 cm) |
| Element #1 Wattage | 1500.0 |
| Element #2 Size | 6.0" (15 cm) |
| Element #2 Wattage | 1500.0 |
| Element #3 Size | 6.0" (15 cm) |
| Element #3 Wattage | 1500.0 |
| Element #4 Size | 8.0" (20 cm) |
| Element #4 Wattage | 2400.0 |
| Burner Controls | Dial |
| Oven Controls | Dial |
| Oven Light | Yes |
| Cooking Timer | Yes |
| Backguard | Yes |
| Backguard Display | Yes |
| Oven Window | Yes |
| Oven Interior Height | 14.0" (36 cm) |
| Oven Interior Width | 24.0" (61 cm) |
| Oven Interior Depth | 19.0" (48 cm) |
AVAILABLE UPGRADES
| Exterior | ||
|---|---|---|
|
FEATURES
30" wide 220V electric range with coil elements and a full-sized oven
Designed and constructed domestically
Standard size ideal for most kitchens
Shallower fit is ideal for L-shaped and galley kitchens
Doors and backguard are constructed from brushed stainless steel for modern luxury built to last
Curved handles in brushed stainless steel offer an easier grip in attractive style
Three standard 6" 1500W and one large 8" 2400W element
Designed to comply with the latest UL safety standards, the elements include a sensor that will cycle the element off and on if it reaches flashpoint temperature
Each coil element includes a removable chrome pan for easier cleaning
Bottom drop-down compartment is ideal for storing cookware, helping to free up space in your small kitchen
Door includes a window and exterior on/off rocker light switch, making it easier to monitor your cooking without opening the door
Broiler is located inside the oven, eliminating the need to transfer contents to a separate compartment towards the floor
Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
8" high backguard helps to protect your walls from spills and splashes
Backguard includes time readout
All knobs are located in the front of the range, letting you adjust your heating without reaching over hot burners
Burner knobs require a small amount of force to turn on for added protection against accidents; oven knob is not push-to-turn
Control panel includes an 'on' light for the oven and burners for added safety when using the range
Smart design limits the depth and protects adjacent cabinets
Solid construction built to hold up to everyday use
Allows for easier cleaning as needed
Two-piece porcelain broiler tray with grease well
Included for user installation to help prevent tipping
Compatible with standard 40 amp 3 or 4-wire range cords
Upfront controls and easy-to-operate knobs offer easier accessibility that complies with the Americans for Disabilities Act (ADA) guidelines
DESCRIPTION
Summit Appliance offers a wide selection of American-made household ranges built for long-lasting durability in space-challenged kitchens. The TEM230BKWY is an apartment-sized 220V electric range sized at 30" wide, with a generous 3.7 cu.ft oven interior that can accommodate large trays. The oven window and interior light with an on/off switch make it easy to monitor your cooking without opening the door. Two adjustable oven racks are included. The waist-high broiler is located inside the oven, allowing you to switch functions without moving contents to a separate compartment on the floor. The lower drop-down storage compartment is ideal for keeping pots and pans out of the way in small kitchens. Designed to meet the most current UL-858 safety standards, this unit features one 8" 2400W and three 6" 1500W coil elements with a safety sensor that will cycle the element off before reaching dangerous flashpoint temperatures. Heating resumes automatically. Upfront push-to-turn knobs offer additional protection, ensuring users won't reach over hot burners to adjust the heat. Stainless steel doors feature professional style towel bar handles, bringing classic elegance to smaller kitchen spaces.The deluxe 8" high backguard includes a digital clock and timer for added convenience when cooking. This unit has a recessed oven door and is conveniently sized at just 24" deep for a better fit in galley in L-shaped kitchens, where every inch counts. We include an anti-tip bracket for added safety. This unit does not include a line cord (a standard 40 amp 3 or 4-prong cord can be installed by your electrician). With its classic style and quality construction, Summit's made in the USA cooking line offers reliable cooking for smaller homes. Additional choices are available in 20", 24", and 36" wide fits.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
