24" Wide Electric Wall Oven
Next day shipping; multi-piece orders may extend lead time. Call 718-893-3900 ext. 507 to discuss
(88cm H x 61cm W x 61cm D)
SPECIFICATIONS
Overview
|
|
---|---|
Nominal Height | 35.0" (89 cm) |
Height of Cabinet | 34.5" (88 cm) |
Nominal Width | 24.0" (61 cm) |
Width | 24.0" (61 cm) |
Nominal Depth | 24.0" (61 cm) |
Depth | 24.0" (61 cm) |
Depth with Handle | 25.38" (64 cm) |
Depth with door at 90° | 42.75" (109 cm) |
Capacity | 2.92 cu.ft. (83 L) |
Door | Stainless Steel |
Cabinet | - |
US Electrical Safety | CSA |
Amps | 40.0 |
Voltage/Frequency | 220 V AC/60 Hz |
Weight | 170.0 lbs. (77 kg) |
Parts & Labor Warranty | 1 Year |
UPC | 761101053035 |
Electric Walloven
|
|
Controls | Dial |
Oven Light | Yes |
Cooking Timer | Yes |
Digital Clock | Yes |
Cleaning Type | Manual |
Oven Rack Qty | 2 |
Oven Window | Yes |
Interior Height | 14.0" (36 cm) |
Interior Width | 19.0" (48 cm) |
Interior Depth | 18.0" (46 cm) |
Cutout Height | 34.13" (87 cm) |
Cutout Width | 22.38" (57 cm) |
Cutout Depth | 23.0" (58 cm) |
FEATURES
Designed and constructed domestically
Sized to fit 34 1/8" H x 22 3/8" W cabinet cutouts, a popular replacement size rarely offered by other manufacturers
2.92 cu.ft. interior to fit large dishes
Doors and control panel are constructed from brushed stainless steel for modern luxury built to last
Curved handles in brushed stainless steel offer an easier grip in attractive style
Bottom drop-down compartment is ideal for storing cookware, helping to free up space in your small kitchen
Door includes a window and exterior on/off rocker light switch, making it easier to monitor your cooking without opening the door
Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
Upper heating element is located inside the oven so there is no need to transfer dishes to another compartment for broiling
Allows for easier cleaning as needed
Solid construction built to hold up to everyday use
Added convenience for easier cooking
Basic knob controls for simple and intuitive cooking
Two-piece porcelain broiler tray with grease well
Compatible with standard 40 amp 3 or 4-wire range cords
Add TKW700SS accessory to raise the exterior height to fit 39" high openings
DESCRIPTION
Summit's classic series of 24" wide wall ovens are made in the USA and specially sized to fit common 34 1/8" H x 22 3/8" W cutouts. The TEM788BKW is a single 220V electric wall oven with a drop-down storage compartment. The exterior doors and manifold come in a brushed stainless steel finish, with full-width curved towel bar handles to complete the look. The oven door includes a window and exterior light switch to illuminate the interior, making it easy to monitor your cooking without opening the door. A digital clock with a timer function offers added convenience and dial controls ensure simple, intuitive cooking. This unit is designed for professional installation and is compatible with a standard 40 amp 3 or 4-wire range cord (not included). Inside, the wall oven features solid porcelain construction for lasting durability to hold up to everyday use. Two adjustable racks with safety brakes allow you to accommodate a variety of sizes when baking. The oven can be used to bake or broil. We include a two-piece broiler tray with grease well. Summit's domestically manufactured wall ovens have an industry exclusive height of 34 1/2". These units fit many discontinued cutouts such as Caloric, Slattery, and older makes, including Magic Chef. To fit other cutouts up to 39" high, add the TKW700SS trim kit accessory.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
