20" Wide Gas Range, Open Burners

SKU: TNM1107BRW
Made in the USA
Estimated Time to Ship:

Next day shipping; multi-piece orders may extend lead time. Call 718-893-3900 ext. 507 to discuss

Backguard:
None 8 Inch

*Additional features may vary

36.0" H x 20.0" W x 24.0" D
(91cm H x 51cm W x 61cm D)

Overview
Height of Cabinet 36.0" (91 cm)
Width 20.0" (51 cm)
Depth 24.0" (61 cm)
Door Stainless Steel
Cabinet Black
US Electrical Safety CSA
Voltage/Frequency 115 V AC/60 Hz
Weight 140.0 lbs. (64 kg)
Parts & Labor Warranty 1 Year
UPC 761101079165
Gas Range
Ignition Spark
LP Convertible With Kit LP Accessory
Oven Capacity 2.46 cu.ft
Cooktop Surface Porcelain
Burner Type Open
Number of Burners 4
Burner #1 BTU 9000.0
Burner #2 BTU 9000.0
Burner #3 BTU 9000.0
Burner #4 BTU 9000.0
Burner Controls Dial
Oven Controls Dial
Oven Light Yes
Cleaning Type Manual
Oven Rack Qty 2
Oven Window Yes
Oven Interior Height 14.0" (36 cm)
Oven Interior Width 16.0" (41 cm)
Oven Interior Depth 19.0" (48 cm)
Broiler Location Below Oven

Exterior
LP Conversion
Have this range factory converted to LP gas. KIT LP is included
Interior
Canadian Range Conversion
Range is modified at factory to meet CSA-C standards

Made in the USA

Designed and constructed domestically

Slim 20 inch width

Apartment-sized width offers all the functionality you need in a smaller footprint

24 inch depth

Shallower fit is ideal for L-shaped and galley kitchens

Slide-in look

Low backguard trimmed in stainless steel makes it easier to integrate your own backsplash design

Stainless steel finish

Doors are constructed from brushed stainless steel for modern luxury built to last

Professional towel bar handles

Curved handles in brushed stainless steel offer an easier grip in attractive style

Four open burners

9000 BTU burners with built-in enamel grates to meet most cooking needs

Designed for natural gas

Set for use with natural gas connection. To convert for propane use, add Kit LP

Electronic ignition

Spark ignition system with a pre-installed 115V 3-prong cord

Oven window and interior lighting

Door includes a window and exterior on/off rocker light switch, making it easier to monitor your cooking without opening the door

Upfront controls

Push-to-turn knobs offer easier, safer access, preventing users from reaching over hot burners to adjust

Recessed oven door

Smart design limits the depth and protects adjacent cabinets

Adjustable oven racks

Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes

Broiler compartment

Lower drop-down compartment for separate broiling with even heat distribution

Porcelain construction

Oven interior features high quality porcelain construction for long-lasting durability, while the cooking surface is made from scratch resistant porcelain enamel

Recessed surface

Smart design helps to contain spills

ADA compliant design

Upfront controls and easy-to-operate knobs offer easier accessibility that complies with the Americans for Disabilities Act guidelines

Anti-tip bracket

Included for user installation to help prevent tipping

Broiler pan included

Two-piece porcelain broiler tray with grease well

Summit Appliance offers a wide selection of American-made household ranges built for long-lasting durability in space-challenged kitchens.

The TNM1107BRW is 20" wide apartment-sized gas range with a generous 2.46 cu.ft porcelain oven interior that can fit large trays. Two adjustable oven racks are included. An oven window and on/off interior light allow you to easily keep watch over your cooking. The broiler is located below the oven in a drop-down compartment. Four open 9000 BTU gas burners accommodate most of your stovetop heating needs, with upfront push-to-turn knobs that let you adjust your cooking without reaching over hot burners. This unit utilizes an electronic ignition system for added safety.

Stainless steel doors feature professional style towel bar handles, bringing classic elegance to smaller kitchen spaces. The low stainless steel trimmed backguard creates a slide-in look, allowing you to customize the space behind your range in the style of your choice. This unit has a recessed oven door and is conveniently sized at just 24" deep for a better fit in galley in L-shaped kitchens, where every inch counts.

With its classic style and quality construction, Summit's made in the USA cooking line offers reliable cooking for smaller homes. Additional choices are available in 24", 30", and 36" wide fits. This unit ships ready for natural gas connections. To use with propane, add the Kit LP.

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
